[精彩实例] 建立一个三维推PIN和一份文件

建立一个三维推PIN和一份文件

在此教程中,我们将展示开始Adobe Illustrator中的艺术家如何建立一个三维推销与三维旋转工具。

We'll learn how to apply highlights and create shadows for a more realistic effect and add a paper note to it

我们将了解如何申请的重点和创造的阴影,为更切合实际的效果并添加了一份文件,说明它

Final Image Preview

最后图片预览

Let's have a look at the image we'll be creating.

让我们看看的形象,我们将创造。

Step 1

第1步

For the 3D Revolve Options in Illustrator, we need to create the front view outline shape of the object we want.

为三维旋转选择在Illustrator中,我们需要创建前端视图轮廓,物体的形状我们希望。

It always goes from the center point to the outline of the object.

它总是从中心点,以纲要的对象。

For example, a globe could be revolved by drawing a half circle.

举例来说,全球可旋转借助一个半圈。

I have illustrated a view possibilities in the image below.

我已说明了期的可能性,在下面的图片。

Step 2

第2步

Lets start with our push pin.

让我们开始与推动的PIN 。

Create a new file.

创建一个新文件。

Drag a vertical guide onto the artboard.

拖动垂直引导到artboard 。

Select the Pen Tool(P), set the fill color to none, and the stroke to black.

选择钢笔工具( P )的设置填充颜色对零票,和中风的黑色。

Note that you can change the color at anytime later on.

请注意,您可以改变颜色在任何时候,稍后。

Then draw a line, as you see in the image below.

然后以此为限,正如你看到在下面的图片。

Step 2

第2步

Select the path and open the Revolve Window under Effects > 3D > Revolve.

选择路径和打开窗口的旋转效应下>三维>旋转。

Step 3

第3步

As you can see, we have quite a few options to apply to our path.

你可以看到,我们有好几个方案,以适用于我们的道路。

Select the Preview option.

选择预览选项。

This will give us a live view of our object.

这将给予我们一个活鉴于我们的对象。

Chose the following settings: X axis of -35 degrees, Y axis of -28 degrees, Z axis of 38 degrees, and leave the Perspective at 0.

选择以下设置: X轴的-35度, Y轴的-28度, Z轴38度,和离开的角度来看,在0 。

Click the More Options Button.

点击更多的选项按钮。

Underneath the Revolve tab, you will see the Surface Options.

下旋转选项卡上,您会看到表面的选择。

Let's have a closer look at the options.

让我们仔细看看该选项。

You can see one Highlight Point that we can move around by clicking and dragging it.

你可以看到一个突出的一点,我们可以走动,点击并拖动它。

We can also change the intensity of the lights.

我们也可以变更强度的灯光。

If we choose to, we can add more highlight points by clicking the New light button.

如果我们选择,我们可以添加更多的强调点,按一下新的轻按钮。

In our case, we don't need to change anything.

在我们的情况下,我们不需要任何改变。

But you can play around and add more highlights if you'd like.

但你可以发挥靠近并添加更多亮点如果您想要。

Step 4

第4步

Open the Swatch Palette and go to Open Swatch Library and select the Earthtone swatches.

开放Swatch的调色盘,并转到开放, Swatch的图书馆,并选取大地swatches 。

I chose a nice red color.

我选择了好红色。

Select the path of the 3D pin and change the color.

选择路径的三维PIN和改变颜色。

You can of course choose any color you prefer.

你当然可以选择任何您喜欢的颜色。

Step 5

第5步

Let's create the metal pin.

让我们创造的金属针。

Draw a shape like you see in the image below.

制定一个形状像你看到在下面的图片。

Make sure that the two points are vertically aligned.

作出肯定的是,有两点是垂直对齐。

You can achieve this by selecting them both with the Direct Selection Tool (A), and press Command + Alt + J to open the Average Palette.

您可以达到这个选择,他们都与直接选择工具(一) ,按Command +按ALT + J至开放的平均调色盘。

From there choose Vertical.

从有选择垂直。

Then click OK.

然后单击确定。

Step 6

第6步

Select the path and open the 3D Revolve Options again.

选择的路径和开放的三维旋转选项。

We'll choose the same settings, since the pin will have to be aligned with the head, but we will add two more highlights.

我们会选择相同的设置,自销将须符合头部,但我们会再添加两个亮点。

Align them as you see in the image below.

使其作为您会看到在下面的图片。

Make sure you have the Preview selected.

请确认您已预览选定的。

Step 7

第7步

Move the pin upwards and behind the red pin head.

动议针向上的背后,红脚头。

The shortcut for aligning layers and paths is Command + [ (behind) and Command + ] (in front).

捷径调整层和路径是指挥+ [ (背后)和指挥+ ] (在前面) 。

Step 8

第8步

Select the red head shape and choose Overlay in the Transparency Palette.

选择红色的头部形状,并选择在重叠的透明度,调色盘。

This will enable us to see the pin and align it better.

这将使我们能够看到PIN和使IT更好。

Step 9

第9步

The pin just looked a little too short, but since we have not expanded any of your 3D effects, we can easily transform the objects.

引脚只是看着有点太短,但由于我们并没有扩大,您的任何3D效果,我们可以很容易改造的对象。

Select the bottom path point with the Direct Selection Tool and lengthen the pin.

选择底部的路径点,与直接选择工具和延长针。

All our 3D effects will be automatically applied.

我们所有的3D效果,将自动适用。

Then set the red head shape back to Normal.

然后设置红色头部形状恢复正常。

Step 10

第10步

Create a new layer underneath the pin layer and call it paper.

创建一个新的层之下的引脚层和称之为文件 。

Create a rectangular shape with the Pen Tool (P).

创建一个矩形形状与笔的工具性( P ) 。

Then choose a light grey color and fill it.

然后选择一个浅灰色的颜色和填补它。

Step 11

第11步

Copy the rectangular shape underneath by pressing Command + C. Then press Command + B and color it with a linear gradient from black to medium grey.

复制矩形形状下,由按下Command +长,然后按Command + B和颜色,它与线性梯度从黑色至中等灰色。

Transform it slightly with the Direct Selection Tool (A) by selecting the points and handles and dragging it around until the shape is a little bigger than the paper shape.

它稍微变换与直接选择工具(一)选择点,并处理和拖动它靠近,直到形状是一个小大于文件的形状。

Step 12

第12步

Select the grey pin part and shorten it so it looks like it pierces through the paper.

选择灰色的PIN的一部分,并缩短它,所以看起来像pierces通过的文件。

You can do this by selecting the bottom path point with the Direct Selection Tool (A) and drag the point upwards.

你可以做到这一点,选择底部的路径点,与直接选择工具( a )和拖曳点向上。

The 3D effect will be automatically adjusted.

三维效果都会自动调整。

Step 13

第13步

Select the red pin head and make a copy.

选择红色的PIN头部和一个副本。

While still selected, go to Object > Expand Appearance.

虽然仍处于选中状态,转到对象>扩大的外观。

This will apply the 3D effect.

这将适用于三维效果。

Step 14

步骤14

Keep the object selected and open the Pathfinder Palette.

保持对象的选定,并打开探路者的调色盘。

Choose Add To Shape Area from the Shapes Modes.

选择添加到形状面积从形状模式。

Step 15

第15步

Fill the shape with black and go to Object > Path > Simplify.

填补形状与黑色并转到对象>路径>简化。

Move the cursor for the Curve Precision to 100%.

将游标移到为曲线精度为100 % 。

This will reduce some points that are unnecessary quickly.

这将减少一些点,是不必要的很快。

Step 16

步骤16

Select our shadow shape, rotate it, scale it, and skew it until it resembles the image below.

选择我们的影子的形状,旋转它,规模,和斜交它,直到它类似于下面的图片。

Step 17

步骤17

Apply a linear gradient that goes from a medium to light grey.

套用线性梯度表示,云从一个中等至浅灰色。

This will make our shadow look more realistic.

这将使我们的阴影,显得更加切合实际。

Step 18

步骤18

Select the paper shape and make a copy on top of it by pressing Command + C + F. Then open the Swatch library patterns by clicking on the Arrow on the right hand side of the Swatch Palette.

选择纸张的形状和作出的副本,再加上它的迫切指挥的C + +楼,然后打开Swatch的图书馆模式,通过点击箭头就右手边的Swatch的调色盘。

In the drop down, choose Open Swatch Library > Patterns > Basic Graphics > Basic Graphic_Textures.

在下拉,选择打开Swatch的资源库 >模式>的基本图形>的基本graphic_textures 。

I chose the pattern called USGS Sewage Disposal.

我选择的模式所谓的美国地质勘探局的污水处理。

Fill the shape with the pattern and set the Transparency to Multiply and its Opacity to 8%.

填写的形状与布局和设置的透明度,以倍数和其不透明至8 % 。

Now we have lined paper.

现在我们有衬里的文件。

Step 19

步骤19

Voila, your very own push pin and note paper.

voila ,您自己推动PIN和注意的文件。

Conclusion

结论

That's all!

这一切!

You can create as many push pins as desired.

您可以创建作为推动许多针,作为理想的。

Pay attention to light sources and set the highlights accordingly.

要注意光源,并设置相应的重点。
